| Project | 315t-A | 315t-B | 315t-C | 315t-D | 500t-A |
500t-B (double cylinder) |
| Liquid maximum working pressure (Mpa) | 25 | 25 | 25 | 25 | 25 | 25 |
| Slider effective stroke(mm) | 400 | 600 | 600 | 800 | 600 | 800 |
| Maximum opening height(mm) | 700 | 1000 | 1000 | 1250 | 1000 | 1500 |
| working desk size(mm*mm) | 700*700 | 800*800 | 1000*1000 | 1260*1160 | 1500*1500 | 2500*1400 |
| Dead speed(mm/s) | 60 | 60 | 80 | 100 | 100 | 120 |
| Speed of work(mm/s) | 7 | 6 | 6 | 6-12 | 8-12 | 8-12 |
| Return speed(mm/s) | 60 | 60 | 60 | 60 | 80 | 80 |
| Motor Power(kw) | 15 | 15 | 15 | 22 | 37 | 37 |
| Oil pump displacement(ml/r) | 63 | 63 | 63 | 80 | 126 | 126 |
| Ejection force(t) | 50 | 50 | 63 | 63 | 100 | 100 |
| Ejection stroke(mm) | 300 | 300 | 300 | 300 | 300 | 350 |
Product details:
