Deep Drawing Hydraulic Press 200 ton _Tengzhou Dingrun Hydraulic Machinery Factory

YQ27 series sheet tensioning machine, such as deep drawing hydraulic press 200 ton, hydraulic machine for the plastic material compression process, such as stamping, bending, flanging sheet stretching, and can be engaged in correction, press fit, plastic products, powder products, compression molding.

Deep Drawing Hydraulic Press 200 ton Specifications:

Model		200T
Nominal force (KN)		2000
Max liquid working force (Mpa)		25
Hydraulic cushion force (KN)		630
Max stroke of hydraulic cushion (mm)		250
Size of the hydraulic cushion (mm)		760x660
Max opening height (mm)		1100
Slide stoke (mm)		700
Slide speed (mm/s)	Decent	100
	Working	12-18
	Return	70
Working table size (mm)		920x900
Motor power (KW)		15

YQ27 series sheet tensioning machine, such as deep drawing hydraulic press 200 ton, hydraulic machine for the plastic material compression process, such as stamping, bending, flanging sheet stretching, and can be engaged in correction, press fit, plastic products, powder products, compression molding.

Dingrun Forging MachineryPlant specializes in four-post hydraulic press, deep drawing hydraulic press 200 ton, sheet tension hydraulic press, single column hydraulic press and gantry hydraulic press for more than ten years. We can customize different countertops and tonnage hydraulic press according to customer's requirement.

We all hydraulic press, deep drawing hydraulic press 200 ton, sheet tension machines have CE certification, each year to participate in the exhibition, welcome friends abround to come to discuss and guidanc.
