600 ton powder forming four column hydraulic press specifications:

project	600T-A	200T-AK	200T-AZS	600T-B	200T-BK	200T-BZS	200T-C	200T-CK	200_CZS	200T-TKS
Max liquid working presure(Mpa)	25	25	25	25	25	25	25	25	25	25
Slide stroke(mm)	600	600	600	900	600	600	900	600	600	600
Max openging height(mm)	1200	1000	1000	1500	1000	1000	1500	1000	1000	1000
Worktable size(mm*mm)	1200*1000	660*660	660*660	1600*1600	800*800	800*800	2200*1600	1000*1000	1000*100	1260*1200
Descent speed(mm/s)	100	100	190	100	100	190	100	100	190	100
Working speed(mm/s)	5-12	6-12	12-18	5-12	6-12	12-18	5-12	6-12	12-18	6-12
Return speed(mm/s)	90	70	100	90	70	160	80	70	160	100
Motor power(KW)	22*2	7.5	11	22*2	7.5	11	22*2	7.5	11
Displacedment oil pump(ml/r)	40	40	63	40	40	63	40	40	63
Knock-out pressure(t)	100	35	35	100	50	50	100	50	50	50
Stroke of knock-out(mm)	350	250	250	350	250	250	350	250	250	300

Punching cushioning installation Mixing installation(hydraulic or Mechanical) Movement working table Touching industry display screen Cooling installation PLC programmable control system Light curtain Safety Protector can be ordered various types of under cylinder Fluctuate slideway and rolling bracket for changing mould 20t—2000T can be produced according to customer`s requirement.

Product details:

600 ton powder forming four column hydraulic press usage:

It is used in metal stamping, steel punching, turning,cold extrusion and other stamping rocesses.

It can also be used for calibration,powder products, plastic products, and insulation materials.

Ultra High Pressure:
The pressure output is stable and the stamina is sufficient.
Super performance:
Compared to the product China manufacturer itself, super low price, low cost.

Super custom:
With the user's needs continue to improve hydraulic press machine design, accumulated experience, to achieve perfect custom.

Super sturdy:
Fine materials, patiently repeated processing, fully craft support to ensure the strength of the structure

Ultra quiet working:
Pressure system to optimize the upgrade, and finally close to perfect, remove your worries.
No leaking:
Precision mechanical combination, the perfect overall cooperation.

Super performance:Compared to the product China manufacturer itself, super low price, high cost.
Super sturdy:Fine materials, patiently repeated processing, fully craft support to ensure the strength of the four column hydraulic press structure

Super customized:With the user's needs continue to improve the hydraulic press design, accumulated experience, to achieve perfect custom.

four column hydraulic press adopts visual operation interface, graphical operation and guidance, and it is very simple to get started.
In terms of man-machine interaction, 1000 ton hydraulic press fully takes into account the specific requirements for use, manual, semi-automatic, fully automatic control, free to switch at any time.
Nominal pressure, opening height, slider stroke, operating speed, China manufacturer hydraulic press worktable size, length and width of the fuselage, can be customized according to your special requirements.
