Specifications :
Tengzhou Dingrun four columns series hydraulic press Septic tank molding compounds Hydraulic Press Machine manufacturer with 1200 Ton Smc Septic Tank Hydraulic Press Machine
hydraulic press is used in SMC / BMC products forming SMC / BMC mahole cover making,
SMC / BMC Septic tank making, SMC / BMC bus body making,
SMC / BMC door producing, SMC / BMC Septic tank heat forming,
SMC / BMC container and utensil boxes making.
| Model | 1200T (three cylinder) | |
| Max.Liquid pressure (Mpa) | 25 | |
| Slide Stroke (mm) | 1800 | |
| Max opening height (mm) | 2600 | |
|
Working table size (mm) |
L-R(between columns) | 3500 |
| F-B(side to side) | 2400 | |
| Descent speed (mm/s) | 120-150 | |
| Working speed (mm/s) | 5-15 | |
| Return speed (mm/s) | 80-120 | |
| Ejecting force (KN) | 1600 | |
| Ejecting stoke (mm) | 350 | |
| Max lift mould force (KN) | 3200 | |
| Lift mould stroke (mm) | 50 | |
| Adjustable stroke (mm) | 300 | |
Finished products
The four columns series hydraulic press Septic tank molding compounds Hydraulic Press Machine manufacturer with 1200 Ton Smc Septic Tank Hydraulic Press Machine
applies to:
Applicable to metal non-metallic materials pressing process.
(watches, hardware, bicycles, motorcycles, cutlery, kitchen utensils,
automobiles, appliances, rubber, wheels, buttons, gold and silver jewelry, ceramics, powder metallurgy, etc.)
Tengzhou Dingrun Forging Machinery Plant
